UHE25 25M UAV Altimeter Radar is designed for agriculture drone altitude holding to 0.2~25m. The UAV sensors can detect flying height automatically and is compatible to Pixhawk / Ardupilot controller with CAN interface. The radar can adapt various complicated ground condition and environment. By detecting the flying height, it provides the guidance for agriculture plants protection UAVs.
| Features | Specification | Parameters |
| Antenna Feature | Azimuth Angle (3dB) | ±15° |
| Elevation Angle (3dB) | ±4° | |
| Maximum EIRP (dBm) | 30 | |
| Radar Feature | Detection Range | 0.2-25m |
| Ranging Accuracy | 0.02m | |
| Range Resolution | 0.12m | |
| TX Frequency (GHz) | 79 | |
| Refresh Rate (Hz) | 20 | |
| FM Bandwidth (GHz) | 1.5 | |
| System Feature | Working Voltage | 5~24V |
| Operating Temperature | -40℃~85℃ | |
| Power Consumption | 3W | |
| Data Interface | UART/CAN | |
| Dimension | 76*71.5*19.6mm |
Key Features
- 25m detection distance;
- 2mm detection accuracy;
- Adapt to Pixhawk/Ardupilot flight controller;
- IP67 protect level;
- UART/CAN interface;
- Tiny size with only 87g;
Radar shall be installed at the bottom of the UAV with wires towards ahead. After being connected, the radar sensor can read the detection perfectly.
